Tonnage (tons) 38
Machine operating weight (kg) 37800-41100
Bucket capacity (m³) 1.35-3
Boom length (mm) 6450
Arm length (mm) 2600
Origin Korea
Performance
Slewing speed (rpm) 10.3
Travel speed (km/h) 3.4/5.3
Gradability (%) 35°
Ground pressure (Kpa) 68.1 (equipped with 600mm crawler shoes)
Bucket digging force (kN) 221.7 (standard) / 242.7 (afterburner)
Arm digging force (kN) 144.4 (standard) / 157.4 (afterburner)
Power system
Engine model Volvo D13H-D
Rated power (kw/rpm) 215/1700
Displacement (L) 12.8
Number of cylinders (pcs) 6
Cylinder diameter × stroke (mm) 131 × 158
Cooling method Water cooling
Working mode Air-to-air cooling, meeting US Tier4i and EU IIIB emission standards
Hydraulic system
Main pump type Variable axial piston pump × 2 + pilot gear pump
Travel hydraulic motor type Variable axial piston motor (with mechanical brake)
Swing hydraulic motor type Fixed displacement axial piston motor (with mechanical brake)
Main pump maximum flow (l/min) 300 × 2 + 25.5
Pilot oil circuit (MPa) 3.9
Working hydraulic oil circuit (Mpa) 32.4/35.3
Travel hydraulic circuit (Mpa) 35.3
Swing hydraulic circuit (Mpa) )27.9
Boom cylinder – number × cylinder diameter × stroke (mm) 2-160 × 1530
Arm cylinder – number × cylinder diameter × stroke (mm) 1-175 × 1750
Bucket cylinder – number × cylinder diameter × stroke (mm) 1-145 × 1285
Oil capacity
Fuel tank (L) 620
Hydraulic oil tank (L) 227
Hydraulic system (L) 485
Engine oil replacement (L) 42
Coolant (L )60
Main dimensions
Total length for transport (mm) 11330
Total width for transport (mm) 3340
Total height for transport (mm) 3590 (total height of boom)
Total height of cab (mm) 3197
Total length of crawler track (mm) 5180
Shoe width (mm) Three-tooth 600/700/800/900; Double-tooth 600
Total width of crawler track (mm) 3340
Track gauge (mm) 2740
Minimum ground clearance (mm) 500
Counterweight ground clearance (mm) 1210
Minimum turning radius of front working device (mm) 4300
Rear end turning radius (mm) 3560
Operating range
Maximum digging radius (mm) 10550
Maximum digging radius of parking surface (mm) 11520
Maximum digging depth (mm) 6850
Maximum digging height (mm) 10170
Maximum unloading height (mm) 7 090
Maximum vertical excavation depth (mm) 5350
Maximum effective excavation depth (mm) 8000
